Hola

Description

Direct/Indirect LED pendant luminaire using linear SMD light sources and a DC constant current power supply integrated in the product. The luminaire body is made from extruded aluminium 6060 alloy and consists of sectors that are joint together with diecast connectors which also act as the mounting points for the suspension wire. The length of the suspension wires is easily regulated with adjustable wire holders. The luminaire is fitted with a PMMA diffuserand is available in matte white or matte black powder coating finish. Ingress protection of IP40.

Downloads

  •
  •
  •
  •
  •

Features and Advantages

Direct / Dir+Ind emission


Ø 1200/1500/2000/3000


CRI: 85


CCT: 3000K/4000K


ON-OFF/1-10V/DALI/PUSH/CASAMBI


Matt white / Matt black

Specifications

CCT

3000K3000K
4000K4000K

Isolation class

Class I - Earth contactClass I - Earth contact

Class F

YESYES

CRI

8585

Incandescent wire

650°650°

Protection class

IP40IP40

General/Office Lighting

Direct
Direct+Indirect

Lifetime

L80B10 50.000 h

Control System

1-10V1-10V
CASAMBICASAMBI
DALIDALI
PUSHPUSH

Configurator

Product Configurator

Product Code :

Technical files of the selection
