Spot 230 Revo Medium Multimetrik

Description

Multimetrik integrates REVO optical technology, offering a regulation system that allows the adjustment of light emission based on specific application needs. The light beam is adjustable from 15° to 60° thanks to the micro-translation of the focal length, ensuring precision and uniformity.

The light intensity can be modulated through an on-board dimmer, whereas, in the EASYMETRIK version, you can choose the color temperature between 2700K, 3200K, and 4000K. The luminous efficiency reaches up to 132 lm/W with flux up to 3500 lm, maintaining a high-quality standard.

The compact design allows integration into Exenia products without altering their aesthetics, ensuring visual continuity with the fixed-beam versions. Interchangeable lenses enable precise and uniform beams, making Multimetrik a versatile solution for various applications.

Available in Medium, Compact, and Max variants, with options for dynamic white (2700K-4000K) or fixed temperatures (2700K, 3000K, 3500K, 4000K), with a CRI of up to 98 and color tolerance up to 2 MacAdam Steps.

Downloads

  •
  •
  •
  •
  •

Features and Advantages

Ø 61mm


CRI: 92/98


CCT: 2700K/3000K/3500K/4000K/TW(2700K-4000K)


UGR<10


ON-OFF/PHASE CUT/DALI/POTENTIOMETER/CASAMBI


2 Variable Optics


6 Finishes

Specifications

CCT

2700K2700K
3000K3000K
3500K3500K
4000K4000K
DW (2700K - 4000k)DW (2700K - 4000k)

Certification

CE ComplianceCE Compliance

Isolation class

Class II - Double insulationClass II - Double insulation

Class F

YESYES

CRI

9292
9898

Incandescent wire

650°650°

Warranty

5 years5 years

Protection class

IP40IP40

Control System

CASAMBICASAMBI
DALIDALI
POTENTIOMETERPOTENTIOMETER

Operating temperature

-10° / +35°-10° / +35°

Variable Beam Lighting

Multimetrik Full Range 15°-36° / 32°-60°Multimetrik Full Range 15°-36° / 32°-60°
Multimetrik Spot 15°-36°Multimetrik Spot 15°-36°
Multimetrik Wide 32°-60°Multimetrik Wide 32°-60°
